Adet bazlı fiyat
- 1+ adet$2.22
- 10+ adet$2.09
- 100+ adet$1.98
- 500+ adet$1.86
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Yayın Yılı
- 2014
- Parça Durumu
- Obsolete
- Contact Materials
- Phosphor Bronze
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- Solder Retention
- Contact Finish
- Gold
- Mating Cycles
- 10
- Fabrika Tedarik Süresi
- 16 Weeks
- Seri
- Easy-On 503566
- Nominal Gerilim
- 50V
- Terminal
- Solder
- Current Rating Amps
- 0.2A
- Pitch
- 0.012 0.30mm
- Cable End Type
- Tabbed
- Actuatorcolor
- Black
- Ambalaj
- Tape & Reel (TR)
- Height Above Board
- 0.037 0.95mm
- Material Flammability Rating
- UL94 V-0, UL94 HB
- Ffc Fcb Thickness
- 0.20mm
- Locking Feature
- Flip Lock
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Montaj Tipi
- Surface Mount, Right Angle
- Housing Color
- White
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flat Flex Type
- FPC
- Çalışma Sıcaklığı
- -40°C~85°C
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Pozisyon Sayısı
- 51
