Adet bazlı fiyat
- 1+ adet$2.32
- 10+ adet$2.19
- 100+ adet$2.07
- 500+ adet$1.95
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Current Rating Amps
- 0.2A
- Terminal
- Solder
- Actuatorcolor
- Black
- Pitch
- 0.012 0.30mm
- Cable End Type
- Tabbed
- Nominal Gerilim
- 50V
- Reference Standard
- UL
- Contact Pattern
- RECTANGULAR
- Seri
- Easy-On 503566
- HTS Kodu
- 8536.69.40.51
- Contact Finish
- Gold
- Mating Cycles
- 10
- Parça Durumu
- Obsolete
- Yayın Yılı
- 2015
- Mounting Option1
- LOCKING
- Özellikler
- Solder Retention
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Phosphor Bronze
- Insulation Resistance
- 50000000Ohm
- Reliability
- COMMERCIAL
- Pozisyon Sayısı
- 37
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Çalışma Sıcaklığı
- -40°C~85°C
- Insulator Color
- NATURAL
- Flat Flex Type
- FPC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Montaj Tipi
- Surface Mount, Right Angle
- Housing Color
- White
- Locking Feature
- Flip Lock
- Kurşunsuz Kodu
- yes
- Ffc Fcb Thickness
- 0.20mm
- Material Flammability Rating
- UL94 V-0, UL94 HB
- Sıra Sayısı
- 1
- Ambalaj
- Tape & Reel (TR)
- Height Above Board
- 0.037 0.95mm
- Total Number Of Contacts
- 37
