Adet bazlı fiyat
- 1+ adet$1.73
- 10+ adet$1.63
- 100+ adet$1.54
- 500+ adet$1.45
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pitch
- 0.012 0.30mm
- Cable End Type
- Tabbed
- Actuatorcolor
- Black
- Material
- Bronze
- Terminal
- Solder
- Current Rating Amps
- 0.2A
- Reference Standard
- UL
- Nominal Gerilim
- 50V
- Contact Location
- Bottom
- Seri
- Easy-On 503566
- Contact Pattern
- RECTANGULAR
- Akım Değeri
- 200mA
- Number Of Contacts
- 27
- Gender
- Receptacle
- Reach Svhc
- Unknown
- Fabrika Tedarik Süresi
- 8 Weeks
- Mating Cycles
- 10
- Contact Finish
- Gold
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Phosphor Bronze
- Özellikler
- Solder Retention
- Mounting Option1
- LOCKING
- Parça Durumu
- Obsolete
- Yayın Yılı
- 2011
- Reliability
- COMMERCIAL
- Insulation Resistance
- 50000000Ohm
- Insulator Color
- NATURAL
- Çalışma Sıcaklığı
- -40°C~85°C
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flat Flex Type
- FPC
- Stackable
- No
- Housing Color
- White
- Montaj Tipi
- Surface Mount, Right Angle
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Elv
- Compliant
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Locking Feature
- Flip Lock
- Material Flammability Rating
- UL94 V-0, UL94 HB
