Adet bazlı fiyat
- 1+ adet$1.52
- 10+ adet$1.43
- 100+ adet$1.35
- 500+ adet$1.27
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Kurşunsuz Kodu
- yes
- Locking Feature
- Flip Lock
- Stackable
- No
- Montaj Tipi
- Surface Mount, Right Angle
- Housing Color
- White
- Elv
- Compliant
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flat Flex Type
- FPC
- Çalışma Sıcaklığı
- -40°C~85°C
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Halogen Free
- Low Halogen
- Kılıf / Paket
- SMD/SMT
- Flammability Rating
- UL94 V-0
- Height Above Board
- 0.037 0.95mm
- Ambalaj
- Cut Tape (CT)
- Sıra Sayısı
- 1
- Material Flammability Rating
- UL94 V-0, UL94 HB
- Ffc Fcb Thickness
- 0.20mm
- Orientation
- Right Angle
- Akım Değeri
- 200mA
- Number Of Contacts
- 21
- Seri
- Easy-On 503566
- Contact Location
- Bottom
- Nominal Gerilim
- 50V
- Cable End Type
- Tabbed
- Pitch
- 0.012 0.30mm
- Material
- Bronze
- Actuatorcolor
- Black
- Terminal
- Solder
- Current Rating Amps
- 0.2A
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Phosphor Bronze
- Özellikler
- Solder Retention
- Yayın Yılı
- 2011
- Parça Durumu
- Obsolete
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 8 Weeks
- Mating Cycles
- 10
- Contact Finish
- Gold
