Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Dielectric Withstanding Voltage
- 200VAC V
- Çalışma Sıcaklığı
- -40°C~85°C
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Seri
- BackFlip, Easy-On 503480
- Yayın Yılı
- 2015
- Montaj Tipi
- Surface Mount, Right Angle
- Contact Finish
- Gold
- Contact Style
- BELLOWED TYPE
- Mounting Option1
- LOCKING
- Actuatorcolor
- Black
- Additional Feature
- ROHS COMPLIANT
- HTS Kodu
- 8536.69.40.40
- Current Rating Amps
- 0.5A
- Locking Feature
- Flip Lock, Backlock
- Ffc Fcb Thickness
- 0.30mm
- Connector Type
- FFC/FPC CONNECTOR
- Board Mounting Option
- FITTING NAIL
- Fabrika Tedarik Süresi
- 10 Weeks
- Cable End Type
- Straight, Tapered
- Sıra Sayısı
- 1
- Pcb Contact Pattern
- RECTANGULAR
- Terminal
- Solder
- Contact Finish Thickness
- 3.94μin 0.10μm
- Ambalaj
- Tape & Reel (TR)
- Contact Pattern
- RECTANGULAR
- Body Depth
- 0.142 inch
- Pozisyon Sayısı
- 18
- Number Of Pcb Rows
- 1
- Mating Cycles
- 10
- Reference Standard
- UL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Solder Retention
- Parça Durumu
- Active
- Insulation Resistance
- 50000000Ohm
- Housing Color
- White
- Nominal Gerilim
- 50V
- Height Above Board
- 0.039 1.00mm
- Contact Materials
- Phosphor Bronze
- Reliability
- COMMERCIAL
- Body Breadth
- 0.039 inch
