Teknik Özellikler
- Actuatorcolor
- Black
- Mounting Option1
- LOCKING
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Çalışma Sıcaklığı
- -40°C~85°C
- Montaj Tipi
- Surface Mount, Right Angle
- Contact Finish
- Gold
- Yayın Yılı
- 2010
- Contact Resistance
- 80mOhm
- Seri
- BackFlip, Easy-On 503425
- Contact Pattern
- RECTANGULAR
- Pozisyon Sayısı
- 61
- Ambalaj
- Tape & Reel (TR)
- Contact Finish Thickness
- 3.94μin 0.10μm
- JESD-609 Kodu
- e4
- Mating Cycles
- 10
- Fabrika Tedarik Süresi
- 9 Weeks
- Ffc Fcb Thickness
- 0.20mm
- HTS Kodu
- 8536.69.40.51
- Current Rating Amps
- 0.2A
- Locking Feature
- Flip Lock, Backlock
- Pcb Contact Pattern
- RECTANGULAR
- Terminal
- Solder
- Cable End Type
- Notched
- Sıra Sayısı
- 1
- Nominal Gerilim
- 50V
- Housing Color
- White
- Insulation Resistance
- 50000000Ohm
- Parça Durumu
- Active
- Reliability
- COMMERCIAL
- Contact Materials
- Copper Alloy
- Height Above Board
- 0.047 1.20mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Solder Retention
- Total Number Of Contacts
- 61
- Material Flammability Rating
- UL94 V-0
- Pitch
- 0.012 0.30mm
- Flat Flex Type
- FPC
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Actuator Material
- Polyphenylene Sulfide (PPS), Glass Filled
