5027905091

Teknik Özellikler

Cable End Type

Tabbed

Parça Durumu

Active

RoHS Durumu

ROHS3 Compliant

Housing Material

Liquid Crystal Polymer (LCP), Glass Filled

Nominal Gerilim

50V

Ambalaj

Tape & Reel (TR)

Ffc Fcb Thickness

0.30mm

Pitch

0.020 0.50mm

Housing Color

Beige

Pozisyon Sayısı

50

Montaj Tipi

Surface Mount, Right Angle

Din Conformance

NO

Contact Finish Thickness

2.00μin 0.051μm

Contact Finish

Gold

Ul Flammability Code

94V-0

Flat Flex Type

FPC

Terminal

Solder

Seri

Easy-On 502790

Mixed Contacts

NO

ECCN Kodu

EAR99

Nem Hassasiyeti (MSL)

1 (Unlimited)

Actuatorcolor

Black

Total Number Of Contacts

50

Özellikler

Double Contact, Solder Retention, Zero Insertion Force (ZIF)

Current Rating Amps

0.5A

Fabrika Tedarik Süresi

8 Weeks

HTS Kodu

8536.69.40.51

Locking Feature

Flip Lock

Actuator Material

Polyphenylene Sulfide (PPS), Glass Filled

Material Flammability Rating

UL94 V-0

Contact Gender

FEMALE

Yayın Yılı

2016

Height Above Board

0.098 2.50mm

JESD-609 Kodu

e4

Contact Materials

Phosphor Bronze

Filter Feature

NO

Option

GENERAL PURPOSE

Kurşunsuz Kodu

yes

Iec Conformance

NO

Sıra Sayısı

1
