Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Finish
- Gold
- Contact Finish Thickness
- 3.94μin 0.10μm
- Reliability
- COMMERCIAL
- Pitch
- 0.012 0.30mm
- Ambalaj
- Tape & Reel (TR)
- Max Voltage Rating Dc
- 50V
- Mounting Option1
- LOCKING
- Housing Color
- White
- Contact Resistance
- 60mOhm
- RoHS Durumu
- ROHS3 Compliant
- Sıra Sayısı
- 1
- Height Above Board
- 0.045 1.14mm
- Mating Cycles
- 10
- Kurşunsuz Kodu
- yes
- Locking Feature
- Flip Lock, Backlock
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Current Rating Amps
- 0.2A
- Material Flammability Rating
- UL94 V-0, UL94 HB
- Actuatorcolor
- Black
- Uzunluk
- 15.6mm
- Flat Flex Type
- FPC
- Seri
- BackFlip, Easy-On 502598
- Number Of Contacts
- 45
- Terminal
- Solder
- Contact Pattern
- RECTANGULAR
- Contact Style
- SQ PIN-SKT
- Montaj Tipi
- Surface Mount, Right Angle
- Plating Thickness
- 3.93μin
- Ffc Fcb Thickness
- 0.20mm
- Orientation
- Right Angle
- Insulator Color
- NATURAL
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Cable End Type
- Tapered
- Parça Durumu
- Active
- Pcb Contact Pattern
- STAGGERED
- Depth
- 3.8mm
- Çalışma Sıcaklığı
- -40°C~85°C
- JESD-609 Kodu
- e3
- Contact Materials
- Phosphor Bronze
- Number Of Pcb Rows
- 2
