Adet bazlı fiyat
- 1+ adet$4.75
- 10+ adet$4.48
- 100+ adet$4.23
- 500+ adet$3.99
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Reliability
- COMMERCIAL
- Contact Finish Thickness
- 3.94μin 0.10μm
- Contact Finish
- Gold
- RoHS Durumu
- ROHS3 Compliant
- Housing Color
- White
- Contact Resistance
- 60mOhm
- Pozisyon Sayısı
- 33
- Mounting Option1
- LOCKING
- Ambalaj
- Tape & Reel (TR)
- Pitch
- 0.012 0.30mm
- Kurşunsuz Kodu
- yes
- Mating Cycles
- 10
- Height Above Board
- 0.045 1.14mm
- Sıra Sayısı
- 1
- Actuatorcolor
- Black
- Total Number Of Contacts
- 33
- Body Depth
- 0.15 inch
- Material Flammability Rating
- UL94 V-0, UL94 HB
- Current Rating Amps
- 0.2A
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Locking Feature
- Flip Lock, Backlock
- Plating Thickness
- 3.93μin
- Montaj Tipi
- Surface Mount, Right Angle
- Contact Style
- SQ PIN-SKT
- Contact Pattern
- RECTANGULAR
- Terminal
- Solder
- Seri
- BackFlip, Easy-On 502598
- Flat Flex Type
- FPC
- Pcb Contact Pattern
- STAGGERED
- Nominal Gerilim
- 50V
- Cable End Type
- Tapered
- Parça Durumu
- Active
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Insulator Color
- NATURAL
- Ffc Fcb Thickness
- 0.20mm
- Yayın Yılı
- 2013
- Contact Materials
- Phosphor Bronze
- Number Of Pcb Rows
- 2
- JESD-609 Kodu
- e3
- Çalışma Sıcaklığı
- -40°C~85°C
