Adet bazlı fiyat
- 1+ adet$1.90
- 10+ adet$1.79
- 100+ adet$1.69
- 500+ adet$1.60
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Current Rating Amps
- 0.4A
- Contact Materials
- Phosphor Bronze
- Sıra Sayısı
- 1
- Flat Flex Type
- FFC
- Fabrika Tedarik Süresi
- 20 Weeks
- Yayın Yılı
- 2010
- Material Flammability Rating
- UL94 V-0
- Mating Cycles
- 20
- Ffc Fcb Thickness
- 0.30mm
- Board Mounting Option
- FITTING NAIL
- Height Above Board
- 0.092 2.33mm
- Parça Durumu
- Active
- Insulator Color
- NATURAL
- Pcb Contact Pattern
- RECTANGULAR
- Locking Feature
- Flip Lock
- Montaj Tipi
- Surface Mount, Right Angle
- Number Of Contacts
- 24
- Terminal
- Solder
- Seri
- Easy-On 502244
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Contact Resistance
- 40mOhm
- Actuator Material
- Polyphenylene Sulfide (PPS), Glass Filled
- Mounting Option1
- LOCKING
- Depth
- 5.3mm
- Housing Color
- White
- Contact Location
- Bottom
- Flammability Rating
- UL94 V-0
- Voltage Rated Ac
- 50V
- Max Voltage Rating Dc
- 50V
- Ambalaj
- Tape & Reel (TR)
- Kurşunsuz Kodu
- yes
- Contact Pattern
- RECTANGULAR
- Insulation Resistance
- 50000000Ohm
- Dielectric Withstanding Voltage
- 250VAC V
- RoHS Durumu
- ROHS3 Compliant
- Actuatorcolor
- Black
- Reach Svhc
- No SVHC
- Cable End Type
- Straight
- Reference Standard
- UL
- Akım Değeri
- 400mA
