Adet bazlı fiyat
- 1+ adet$1.81
- 10+ adet$1.70
- 100+ adet$1.61
- 500+ adet$1.52
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Height Above Board
- 0.238 6.05mm
- Mating Cycles
- 20
- Ffc Fcb Thickness
- 0.30mm
- Material Flammability Rating
- UL94 V-0
- Fabrika Tedarik Süresi
- 20 Weeks
- Yayın Yılı
- 2010
- Pcb Contact Pattern
- RECTANGULAR
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Additional Feature
- POLARIZED, EASY-ON
- Contact Materials
- Phosphor Bronze
- Current Rating Amps
- 0.4A
- Flat Flex Type
- FFC
- ECCN Kodu
- EAR99
- Mounting Option2
- LOCKING
- Housing Color
- Natural
- Actuator Material
- Polyamide (PA9T), Nylon 9T, Glass Filled
- Mounting Option1
- LATCH & EJECT
- Contact Resistance
- 40mOhm
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Contact Pattern
- RECTANGULAR
- Kurşunsuz Kodu
- yes
- Option
- GENERAL PURPOSE
- Total Number Of Contacts
- 15
- Ambalaj
- Tape & Reel (TR)
- Iec Conformance
- NO
- Din Conformance
- NO
- Montaj Tipi
- Surface Mount
- Locking Feature
- Flip Lock
- Seri
- Easy-On 502231
- Terminal
- Solder
- Body Depth
- 0.238 inch
- HTS Kodu
- 8536.69.40.51
- Contact Finish
- Gold
- Insertion Forcemax
- ZIF N
- Plating Thickness
- 4μin
- Actuatorcolor
- Brown
- Nominal Gerilim
- 50V
- RoHS Durumu
- ROHS3 Compliant
- Insulation Resistance
- 50000000Ohm
