Adet bazlı fiyat
- 1+ adet$1.73
- 10+ adet$1.63
- 100+ adet$1.54
- 500+ adet$1.45
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- JESD-609 Kodu
- e4
- Contact Pattern
- RECTANGULAR
- Terminal
- Solder
- Contact Resistance
- 80mOhm
- Filter Feature
- NO
- Din Conformance
- NO
- Reference Standard
- UL
- Cable End Type
- Tapered
- Height Above Board
- 0.039 1.00mm
- Flat Flex Type
- FPC
- Mating Cycles
- 10
- Locking Feature
- Flip Lock
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Contact Materials
- Copper Alloy
- Seri
- Easy-On 502078
- Housing Color
- Beige
- Ul Flammability Code
- 94V-0
- Fabrika Tedarik Süresi
- 21 Weeks
- Current Rating Amps
- 0.2A
- Housing Material
- Plastic, Glass Filled
- Reliability
- COMMERCIAL
- Mounting Option1
- LOCKING
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Breadth
- 0.394 inch
- Actuatorcolor
- Black
- Board Mounting Option
- FITTING NAIL
- Insulation Resistance
- 50000000Ohm
- Iec Conformance
- NO
- Çalışma Sıcaklığı
- -20°C~85°C
- Actuator Material
- Plastic, Glass Filled
- Contact Style
- BELLOWED TYPE
- RoHS Durumu
- ROHS3 Compliant
- Pozisyon Sayısı
- 21
- Material Flammability Rating
- UL94 V-0, UL94 HB
- Total Number Of Contacts
- 21
- Contact Gender
- FEMALE
- Yayın Yılı
- 2016
- Kurşunsuz Kodu
- yes
- Pitch
- 0.010 0.25mm
