Teknik Özellikler
- Fabrika Tedarik Süresi
- 13 Weeks
- Kurşunsuz Kodu
- yes
- Depth
- 4.5mm
- Montaj Tipi
- Surface Mount
- Durability
- 20 Cycles
- Parça Durumu
- Active
- Current Rating Amps
- 0.4A
- Contact Finish
- Tin Bismuth
- Actuator Material
- Polyamide (PA9T), Nylon 9T, Glass Filled
- Plating Thickness
- 40μin
- Height Above Board
- 0.159 4.04mm
- Pitch
- 0.020 0.50mm
- Gender
- Receptacle
- Connector Type
- FFC/FPC CONNECTOR
- Option
- GENERAL PURPOSE
- Iec Conformance
- NO
- Locking Feature
- Flip Lock
- Orientation
- Vertical
- Contact Resistance
- 40mOhm
- RoHS Durumu
- ROHS3 Compliant
- JESD-609 Kodu
- e3
- Contact Plating
- Tin
- Contact Style
- BELLOWED TYPE
- Mil Conformance
- NO
- Ul Flammability Code
- 94V-0
- Radyasyon Dayanımı
- No
- Sıra Sayısı
- 1
- Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flat Flex Type
- FFC, FPC
- Housing Color
- White
- Number Of Contacts
- 60
- Reach Svhc
- Unknown
- Contact Pattern
- RECTANGULAR
- Max Voltage Rating Ac
- 50V
- Yayın Yılı
- 2012
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- ECCN Kodu
- EAR99
- Din Conformance
- NO
