Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mil Conformance
- NO
- Ul Flammability Code
- 94V-0
- JESD-609 Kodu
- e3
- RoHS Durumu
- ROHS3 Compliant
- Actuatorcolor
- Brown
- Ffc Fcb Thickness
- 0.30mm
- Sıra Sayısı
- 1
- Housing Color
- White
- Flat Flex Type
- FFC, FPC
- Terminal
- Solder
- Contact Materials
- Copper Alloy
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2008
- Mixed Contacts
- NO
- Seri
- Easy-On 501951
- Çalışma Sıcaklığı
- -25°C~85°C
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Nominal Gerilim
- 50V
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 13 Weeks
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Cut Tape (CT)
- Current Rating Amps
- 0.4A
- Parça Durumu
- Active
- Montaj Tipi
- Surface Mount
- Din Conformance
- NO
- Total Number Of Contacts
- 50
- Height Above Board
- 0.159 4.04mm
- Cable End Type
- Straight, Tapered
- Pitch
- 0.020 0.50mm
- Filter Feature
- NO
- Actuator Material
- Polyamide (PA9T), Nylon 9T, Glass Filled
- Contact Finish
- Tin Bismuth
- Option
- GENERAL PURPOSE
- Locking Feature
- Flip Lock
- Iec Conformance
- NO
- Contact Gender
- FEMALE
- Connector Type
- FFC/FPC CONNECTOR
- Pozisyon Sayısı
- 50
