Adet bazlı fiyat
- 1+ adet$3.69
- 10+ adet$3.48
- 100+ adet$3.28
- 500+ adet$3.10
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Çalışma Sıcaklığı
- -40°C~85°C
- Number Of Pcb Rows
- 1
- Seri
- Easy-On 501864
- Özellikler
- Board Guide, Solder Retention
- Yayın Yılı
- 2016
- HTS Kodu
- 8536.69.40.51
- Reference Standard
- UL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Phosphor Bronze
- Mounting Option1
- LOCKING
- Terminal
- Solder
- Contact Pattern
- RECTANGULAR
- Flat Flex Type
- FFC
- Housing Color
- Black
- Sıra Sayısı
- 2
- Reliability
- COMMERCIAL
- Ffc Fcb Thickness
- 0.30mm
- Insulation Resistance
- 50000000Ohm
- Contact Resistance
- 40mOhm
- RoHS Durumu
- ROHS3 Compliant
- Contact Style
- BELLOWED TYPE
- JESD-609 Kodu
- e4
- Pcb Contact Pattern
- RECTANGULAR
- Pozisyon Sayısı
- 30
- Mating Cycles
- 20
- Contact Finish Thickness
- 3.94μin 0.10μm
- Locking Feature
- Slide Lock
- Body Breadth
- 0.191 inch
- Contact Finish
- Gold
- Body Length Or Diameter
- 0.909 inch
- Pitch
- 0.020 0.50mm
- Body Depth
- 0.315 inch
- Total Number Of Contacts
- 30
- Height Above Board
- 0.191 4.85mm
- Cable End Type
- Notched
- Montaj Tipi
- Surface Mount, Right Angle
- Parça Durumu
- Active
- Current Rating Amps
- 0.5A
- Ambalaj
- Tape & Reel (TR)
- Board Mounting Option
- FITTING NAIL
