5016283591

Teknik Özellikler

Çalışma Sıcaklığı

-25°C~85°C

Current Rating Amps

0.2A

Contact Materials

Copper Alloy

Flammability Rating

UL94 V-0

Depth

3.1mm

Mixed Contacts

NO

Stackable

No

Filter Feature

NO

Cable End Type

Tabbed

Height Above Board

0.035 0.88mm

Elv

Compliant

Gender

Receptacle

Mil Conformance

NO

Locking Feature

Flip Lock

Number Of Contacts

35

Parça Durumu

Obsolete

Contact Finish

Gold

Yayın Yılı

2014

Contact Location

Bottom

Din Conformance

NO

Nominal Gerilim

50V

Kurşunsuz Kodu

yes

Flat Flex Type

FPC

Mating Cycles

10

RoHS Durumu

ROHS3 Compliant

Iec Conformance

NO

Option

GENERAL PURPOSE

Contact Resistance

40mOhm

Terminal

Solder

Akım Değeri

200mA

Montaj Tipi

Surface Mount, Right Angle

Ffc Fcb Thickness

0.20mm

Orientation

Right Angle

Sıra Sayısı

1

Ambalaj

Tape & Reel (TR)

Reach Svhc

Unknown

Ul Flammability Code

94V-0

Actuator Material

Polyamide (PA), Nylon, Glass Filled

Fabrika Tedarik Süresi

12 Weeks

Material Flammability Rating

UL94 V-0
