Teknik Özellikler
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Ul Flammability Code
- 94V-0
- Ambalaj
- Tape & Reel (TR)
- Total Number Of Contacts
- 27
- Pitch
- 0.012 0.30mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Flammability Rating
- UL94 V-0
- Fabrika Tedarik Süresi
- 9 Weeks
- Seri
- Easy-On 501628
- Uzunluk
- 10.2mm
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- JESD-609 Kodu
- e3
- Akım Değeri
- 200mA
- Montaj Tipi
- Surface Mount, Right Angle
- Ffc Fcb Thickness
- 0.20mm
- Orientation
- Right Angle
- Sıra Sayısı
- 1
- Mating Cycles
- 10
- Option
- GENERAL PURPOSE
- Iec Conformance
- NO
- RoHS Durumu
- ROHS3 Compliant
- Contact Resistance
- 40mOhm
- Terminal
- Solder
- Contact Finish
- Gold
- Yayın Yılı
- 2013
- Contact Location
- Bottom
- Nominal Gerilim
- 50V
- Din Conformance
- NO
- Flat Flex Type
- FPC
- Kurşunsuz Kodu
- yes
- Cable End Type
- Tabbed
- Gender
- Receptacle
- Height Above Board
- 0.035 0.88mm
- Locking Feature
- Flip Lock
- Mil Conformance
- NO
- Parça Durumu
- Obsolete
- Contact Materials
- Copper Alloy
- Current Rating Amps
- 0.2A
- Mixed Contacts
- NO
- Flammability Rating
- UL94 V-0
