5014610601

Teknik Özellikler

Body Breadth

0.042 inch

Housing Material

Polymer, Glass Filled

Ambalaj

Tape & Reel (TR)

Contact Finish Thickness

3.94μin 0.10μm

Sıra Sayısı

1

Reference Standard

UL

Montaj Tipi

Surface Mount, Right Angle

Ffc Fcb Thickness

0.12mm

Number Of Pcb Rows

1

Terminal

Solder

Insulator Color

BROWN

Reliability

COMMERCIAL

RoHS Durumu

ROHS3 Compliant

Contact Style

SINGLE PRONG

Mounting Option1

LOCKING

Flat Flex Type

FPC

Cable End Type

Notched

Filter Feature

NO

Pozisyon Sayısı

6

ECCN Kodu

EAR99

Mixed Contacts

NO

Mounting Option2

FRICTION LOCK

Çalışma Sıcaklığı

-40°C~85°C

Insertion Forcemax

ZIF N

Seri

BackFlip 501461

Material Flammability Rating

UL94 V-0

Nem Hassasiyeti (MSL)

1 (Unlimited)

Pitch

0.020 0.50mm

Actuator Material

Polymer, Glass Filled

Ul Flammability Code

94V-0

Total Number Of Contacts

6

Insulation Resistance

50000000Ohm

Contact Resistance

40mOhm

Iec Conformance

NO

Board Mounting Option

FITTING NAIL

Option

GENERAL PURPOSE

Mating Cycles

20

Kurşunsuz Kodu

yes

Pcb Contact Pattern

RECTANGULAR

Nominal Gerilim

50V
