Adet bazlı fiyat
- 1+ adet$0.40
- 10+ adet$0.37
- 100+ adet$0.35
- 500+ adet$0.33
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mating Cycles
- 25
- Montaj Tipi
- Surface Mount, Right Angle
- Seri
- Easy-On 200529
- Flat Flex Type
- FFC, FPC
- Height Above Board
- 0.075 1.90mm
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Ambalaj
- Tape & Reel (TR)
- Contact Materials
- Phosphor Bronze
- Contact Finish
- Tin Bismuth
- Pitch
- 0.039 1.00mm
- Terminal
- Solder
- Locking Feature
- Flip Lock
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Pozisyon Sayısı
- 6
- Cable End Type
- Straight, Tabbed
- Current Rating Amps
- 0.5A per Contact
- Contact Finish Thickness
- 39.4μin 1.00μm
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~85°C
- Actuatorcolor
- Black
- Fabrika Tedarik Süresi
- 18 Weeks
- Housing Color
- Beige
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Material Flammability Rating
- UL94 V-0
- Ffc Fcb Thickness
- 0.30mm
- Yayın Yılı
- 2016
