0781271328

Teknik Özellikler

Mil Conformance

NO

Flat Flex Type

FFC, FPC

Filter Feature

NO

Number Of Circuits

31

Terminal

Solder

Fabrika Tedarik Süresi

11 Weeks

Height Above Board

0.161 4.10mm

Flammability Rating

UL94 V-0

Contact Gender

FEMALE

Ambalaj

Tape & Reel (TR)

Seri

78127

Contact Materials

Copper Alloy

Nem Hassasiyeti (MSL)

1 (Unlimited)

Housing Material

Polyamide (PA46), Nylon 4/6, Glass Filled

Current Rating Amps

0.5A

Mating Cycles

20

Contact Finish

Gold

Total Number Of Contacts

32

Parça Durumu

Active

Nominal Gerilim

50V

Option

GENERAL PURPOSE

Kurşunsuz Kodu

yes

Pozisyon Sayısı

32

Cable End Type

Tapered

Akım Değeri

500mA

Sıra Sayısı

1

Contact Finish Thickness

3.94μin 0.10μm

Orientation

Vertical

Mixed Contacts

NO

Iec Conformance

NO

Ffc Fcb Thickness

0.30mm

Housing Color

Natural

Din Conformance

NO

Montaj Tipi

Surface Mount

Pitch

0.020 0.50mm

Çalışma Sıcaklığı

-40°C~85°C

Material Flammability Rating

UL94 V-0

Montaj

Surface Mount

ECCN Kodu

EAR99

Ul Flammability Code

94V-0
