MLX90217LUA-CAA-000-BU

Teknik Özellikler

Fabrika Tedarik Süresi

18 Weeks

Sensing Range

400mT Trip, 50mT Release

Test Conditions

-40°C ~ 150°C

Max Junction Temperature Tj

175°C

Çıkış Tipi

Open Drain

Montaj Tipi

Through Hole

Max Supply Current

6mA

Function

Special Purpose

Body Length Or Diameter

4.1mm

Polarity

South Pole

Max Output Current

25mA

Yükseklik

4.95mm

Parça Durumu

Active

Operating Supply Voltage

24V

Body Breadth

1.5 mm

Kurşunsuz

Lead Free

Çalışma Sıcaklığı

-40°C~150°C TA

Additional Feature

SHORT CIRCUIT PROTECTION

Besleme Gerilimi

3.5V~24V

JESD-609 Kodu

e3

Nominal Supply Current

3mA

Output Voltage

30V

Nem Hassasiyeti (MSL)

1 (Unlimited)

Output Range

25mA

Termination Type

SOLDER

Hysteresis

3.5 mT

Yayın Yılı

2004

Output Current

25mA

Current Supply Max

6mA

Kılıf / Paket

TO-226-3, TO-92-3 Short Body

Sensing Method

Hall Effect

Ambient Temperature Range High

150°C

Ambalaj

Bulk

Polarization

South Pole

RoHS Durumu

RoHS Compliant

Montaj

Through Hole

Terminal Kaplaması

Matte Tin (Sn)
