SSP-LXS1823S16A

Teknik Özellikler

Shape

ROUND

Mounting Feature

RADIAL MOUNT

Lens Type

WATER CLEAR

Millicandela Rating

1200mcd

Terminal Adımı

2.54mm

Yüzey Montaj

NO

Forward Currentmax

0.03A

HTS Kodu

8541.40.20.00

Renk

Yellow

Tcode

T-3

Terminal Sayısı

20

Operating Temperature Max

70°C

Boyut / Ölçü

1.82Lx1.82W x 0.49 H 46.33mmx46.33mmx12.45mm

Peak Wavelength

590 nm

Configuration

4 x 4

Internal Connection

Common Anode Row, Common Cathode Column

Fonksiyon Sayısı

1

Additional Feature

HIGH RELIABILITY

Parça Durumu

Obsolete

Operating Temperature Min

-30°C

RoHS Durumu

Non-RoHS Compliant

Nem Hassasiyeti (MSL)

1 (Unlimited)

Yayın Yılı

2000

Optoelectronic Device Type

SINGLE COLOR LED ARRAY

Luminous Intensity

1.2 cd

Voltage Forward Vf Typ

2.1V

Yükseklik

6.35mm

Viewing Angle

30 deg

Packing Method

BULK
