Adet bazlı fiyat
- 1+ adet$1.43
- 10+ adet$1.35
- 100+ adet$1.27
- 500+ adet$1.20
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Yayın Yılı
- 2002
- Lens Transparency
- Diffused
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Forward Voltage
- 2V
- Terminal
- Wire Leads
- Reach Svhc
- No SVHC
- Montaj
- Snap in
- Akım
- 30mA
- Operating Temperature Max
- 85°C
- Operating Supply Voltage
- 2V
- Terminal Sayısı
- 2
- Panel Cutout Dimensions
- 0.25 (6.35mm)
- Panel Cutout Shape
- Round
- Overall Height
- 5.5mm
- Parça Durumu
- Active
- Voltage Rated Dc
- 2.5V
- Lens Style
- Round with Domed Top
- Wavelength Peak
- 636nm
- Tip
- LED
- Fonksiyon Sayısı
- 1
- Configuration
- SINGLE WITH BUILT-IN RESISTOR
- Forward Current
- 25mA
- Lens Size
- 3mm T-1
- Millicandela Rating
- 100mcd
- Luminous Intensity
- 100 mcd
- Fabrika Tedarik Süresi
- 16 Weeks
- Ratings
- Vf (Typ), If (Max)
- Number Of Leds
- 1
- Packing Method
- BULK
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Temperature Min
- -40°C
- Viewing Angle
- 60°
- Terminal Stili
- Wire Leads - 6 (152.40mm)
- Kılıf / Paket
- 100
- Lamp Color
- Red
- Kurşunsuz
- Lead Free
