4316-2

Teknik Özellikler

Frekans

12GHz~18GHz

Rfmicrowave Device Type

SPLITTER

Fabrika Tedarik Süresi

15 Weeks

Input Powermax Cw

44.77dBm

Additional Feature

SMA-F, ISOLATION-MIN (DB):19

Kılıf / Paket

Module

Operating Temperature Max

85°C

Boyut / Ölçü

0.750Lx1.000W x 0.375 H 19.05mmx25.40mmx9.52mm

Specifications

Isolation (Min) 19dB

Nem Hassasiyeti (MSL)

Not Applicable

Vswrmax

1.35

Construction

COAXIAL

RoHS Durumu

RoHS Compliant

Operating Temperature Min

-55°C

Insertion Loss

0.7dB

Parça Durumu

Active
