Adet bazlı fiyat
- 1+ adet$72.54
- 10+ adet$68.43
- 100+ adet$64.56
- 500+ adet$60.91
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- Lead Length
- 5.5mm
- Life Hours
- 20000 hours
- Kapasitans
- 4700μF
- Lead Spacing
- 1.252 31.80mm
- Terminal
- Screw
- Terminal Adımı
- 31.8mm
- Leakage Current
- 6mA
- Çalışma Sıcaklığı
- -40°C~85°C
- Ripple Current High Frequency
- 26A @ 10kHz
- Empedans
- 24mOhm
- Montaj
- Chassis Mount
- Voltage Rated Ac
- 400V
- Seri
- ALS31
- Terminal Sayısı
- 2
- Ripple Current Low Frequency
- 18A @ 100Hz
- Lead Diameter
- 13 mm
- Tolerans
- ±20%
- Polarization
- Polar
- Dielectric Material
- Aluminium
- Capacitor Type
- ALUMINUM ELECTROLYTIC CAPACITOR
- Yayın Yılı
- 2009
- Applications
- General Purpose
- Gerilim
- 400V
- Boyut / Ölçü
- 3.032Dia 77.00mm
- Esr Equivalent Series Resistance
- 33mOhm @ 100Hz
- Reference Standard
- IEC60384-4
- ECCN Kodu
- EAR99
- Montaj Tipi
- Chassis Mount
- Kılıf / Paket
- Radial, Can - Screw Terminals
- Yükseklik
- 145.9992mm
- Lifetime Temp
- 20000 Hrs @ 85°C
- Ambalaj
- Bulk
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- Not Applicable
- RoHS Durumu
- ROHS3 Compliant
- Ripple Current
- 18A
- Voltage Rated Dc
- 400V
- Maks. Oturma Yüksekliği
- 5.827 148.00mm
- Lead Pitch
- 31.8008mm
