ALC10C152EG250

Teknik Özellikler

Maks. Oturma Yüksekliği

2.244 57.00mm

Dielectric Material

Aluminium

Lead Diameter

2 mm

Lead Length

6.3mm

Kılıf / Paket

Radial, Can - Snap-In - 4 Lead

Polarization

Polar

Parça Durumu

Active

Life Hours

18000 hours

Empedans

69mOhm

Ripple Current High Frequency

6.58A @ 10kHz

Voltage Rated Dc

250V

Ambalaj

Bulk

Esr Equivalent Series Resistance

89mOhm @ 100Hz

Applications

General Purpose

Nem Hassasiyeti (MSL)

1 (Unlimited)

Tolerans

±20%

Çalışma Sıcaklığı

-40°C~85°C

ECCN Kodu

EAR99

Montaj Tipi

Through Hole

Boyut / Ölçü

1.575Dia 40.00mm

Özellikler

General Purpose

Gerilim

250V

Ripple Current

5.29A

Ripple Current Low Frequency

5.29A @ 100Hz

Lifetime Temp

18000 Hrs @ 85°C

Fabrika Tedarik Süresi

32 Weeks

Reach Svhc

No SVHC

Terminal Sayısı

2

Lead Spacing

0.886 22.50mm

Terminal

Snap in

Yayın Yılı

2003

Seri

ALC10

Leakage Current

6mA

Voltage Rated Ac

250V

RoHS Durumu

ROHS3 Compliant

Lead Pitch

10mm

Test Frequency

100Hz

Kapasitans

1500μF

Montaj

Through Hole

Ripple Current Ac

6.58A
