Adet bazlı fiyat
- 1+ adet$260.55
- 10+ adet$245.80
- 100+ adet$231.89
- 500+ adet$218.77
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Seri
- 83513-Style Micro D Metal Shell (MDM)
- Montaj
- Free Hanging
- Insulation Resistance
- 5000000000Ohm
- ECCN Kodu
- EAR99
- Dielectric Withstanding Voltage
- 900VAC V
- Body Depth
- 0.106 inch
- Insulator Material
- LIQUID CRYSTAL POLYMER (LCP)
- Operating Temperaturemax
- 125 °C
- Rated Current Signal
- 3A
- HTS Kodu
- 8536.69.40.30
- Wire Size
- 26 AWG
- 1st Connector
- Plug, Male Pins
- Housing Material
- Polymer
- Total Number Of Contacts
- 37
- Number Of Rows Loaded
- 2
- Body Length
- 1.485 inch
- Plug Receptacle
- PIN
- Üretici Parça No
- MDM-37PH006B-F222
- Rad Hardened
- No
- Rohs Code
- Yes
- Mounting Option1
- HOLE .087-.098
- Contact Style
- Pin
- JESD-609 Kodu
- e4
- Contact Resistance
- 8mOhm
- Insertion Forcemax
- 2.224 N
- Wire Sizemax
- 26 AWG
- Contact Design
- PREASSEM CONN
- Shell Material
- ALUMINUM ALLOY
- Terminal Length
- 0.2 inch
- Product Depth Mm
- 15.17(mm)
- Wire Sizemin
- 32 AWG
- Contact Pattern
- STAGGERED
- Number Of Contact Rows
- 2
- Body Breadth
- 0.308 inch
- Min. Çalışma Sıcaklığı
- -55°C
- Parça Durumu
- Active
- Number Of Terminals
- 37
- Reference Standard
- UL
- Connector Type
- D-Sub, Plug, Signal
- Contact Finish Mating
- AU
