TLI49632MXTMA1

Teknik Özellikler

Operating Temperature Max

125°C

Output Range

0-5mA

Nem Hassasiyeti (MSL)

1 (Unlimited)

Ambalaj

Tape & Reel (TR)

Sensorstransducers Type

MAGNETIC FIELD SENSOR,HALL EFFECT

Hysteresis

10 mT

Operating Temperature Min

-40°C

Supply Voltagemin Vsup

3V

JESD-609 Kodu

e3

Supply Voltagemax Vsup

5.5V

Yayın Yılı

2015

Usage Level

Automotive grade

Yüzey Montaj

YES

Fabrika Tedarik Süresi

39 Weeks

Magnetic Field Rangemax

7.3 mT

Body Height

1mm

Parça Durumu

Active

Seri

Automotive, AEC-Q100

Terminal Kaplaması

Tin (Sn)

Çıkış Tipi

CURRENT OUTPUT

Mounting Feature

SURFACE MOUNT

Kurşunsuz Kodu

yes

Operating Currentmax

2.5mA

Body Length Or Diameter

2.9mm

Termination Type

SOLDER

Body Breadth

1.3 mm

Magnetic Field Rangemin

-7.3 mT

RoHS Durumu

ROHS3 Compliant

Housing

PLASTIC

Output Currentmax

5mA
