TLE49613MXTSA1

Teknik Özellikler

Housing

PLASTIC

Body Length Or Diameter

2.9mm

Power Supplies

3/32V

Operating Currentmax

2.5mA

Magnetic Field Rangemax

10.4 mT

Output Polarity

INVERTING

Çıkış Tipi

CURRENT OUTPUT

Output Currentmax

25mA

Yayın Yılı

2010

Terminal Sayısı

3

Sensorstransducers Type

MAGNETIC FIELD SENSOR,HALL EFFECT

Output Range

0-25mA

Body Breadth

1.3 mm

Kurşunsuz Kodu

no

Parça Durumu

Active

Output

OPEN-DRAIN

Nem Hassasiyeti (MSL)

1 (Unlimited)

Ambalaj

Tape & Reel (TR)

Fabrika Tedarik Süresi

26 Weeks

Body Height

1mm

Terminal Kaplaması

Tin (Sn)

Seri

Automotive, AEC-Q100

JESD-609 Kodu

e3

Supply Voltagemax Vsup

32V

Input Mode

BIPOLAR(LATCHED)

Termination Type

SOLDER

Usage Level

Automotive grade

Magnetic Field Rangemin

-10.4 mT

Mounting Feature

SURFACE MOUNT

Yüzey Montaj

YES

RoHS Durumu

ROHS3 Compliant

Hysteresis

15 mT

Supply Voltagemin Vsup

3V

Additional Feature

REVERSE POLARITY PROTECTION, OPEN DRAIN OUTPUT
