TC277TP64F200NDCKXUMA1

Teknik Özellikler

Has Adc

YES

Data Converters

A/D 60x12b, 6 x Sigma-Delta

Number Of Adc Channels

60

Oscillator Type

External

Yükseklik

1.7mm

Jesd30 Code

S-PBGA-B292

Number Of Ios

169

Upsucsperipheral Ics Type

MICROCONTROLLER

Ambient Temperature Range High

125°C

Terminal Pozisyonu

BOTTOM

Pwm Channels

NO

Terminal Formu

BALL

Çalışma Sıcaklığı

-40°C~125°C TA

Interface

CAN, Ethernet, I2C, LIN, SPI

Max Junction Temperature Tj

150°C

Frekans

200MHz

Number Of Ad Converters

8

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Bit Size

32

Program Memory Type

FLASH

Tepe Reflow Sıcaklığı (°C)

NOT SPECIFIED

Nem Hassasiyeti (MSL)

3 (168 Hours)

RoHS Durumu

ROHS3 Compliant

Ambalaj

Tape & Reel (TR)

Terminal Sayısı

292

On Chip Program Rom Width

8

Program Memory Size

4MB 4M x 8

Core Size

32-Bit Tri-Core

Fabrika Tedarik Süresi

26 Weeks

Ram Size

472K x 8

Number Of Spi Channels

4

Yüzey Montaj

YES

Connectivity

ASC, CANbus, Ethernet, FlexRay, HSSL, I2C, LINbus, MSC, PSI5, QSPI, SENT

Memory Size

4MB

Yayın Yılı

2010

Kılıf / Paket

292-LFBGA

Eeprom Size

64K x 8

Seri

AURIX™

Core Processor

TriCore™

Data Bus Width

32b
