DZ1070N26KHPSA1

Teknik Özellikler

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Yayın Yılı

2012

ECCN Kodu

EAR99

Nem Hassasiyeti (MSL)

Not Applicable

Reverse Currentmax

150000μA

Configuration

SINGLE

Output Currentmax

1070A

Operating Temperature Junction

-40°C~150°C

Speed

Standard Recovery >500ns, > 200mA (Io)

Current Reverse Leakage Vr

150mA @ 2600V

Case Connection

ISOLATED

REACH Uyumluluk Kodu

compliant

Yüzey Montaj

NO

Number Of Phases

1

Current Average Rectified Io

1070A

Rep Pk Reverse Voltagemax

2600V

Terminal Pozisyonu

UPPER

Diode Element Material

SILICON

Diode Type

Standard

Fabrika Tedarik Süresi

8 Weeks

Number Of Elements

1

Applications

GENERAL PURPOSE

Tepe Reflow Sıcaklığı (°C)

NOT SPECIFIED

Ambalaj

Bulk

Montaj Tipi

Chassis Mount

Kılıf / Paket

Module

Additional Feature

UL RECOGNIZED

Jesd30 Code

R-XUFM-X2

Nonrep Pk Forward Currentmax

35000A

Operating Temperature Max

150°C

HTS Kodu

8541.10.00.80

Parça Durumu

Active

Voltage Forward Vf Max If

1.52V @ 3400A

RoHS Durumu

RoHS Compliant

Terminal Formu

UNSPECIFIED

Voltage Dc Reverse Vr Max

2600V

Terminal Sayısı

2
