DZ1070N18KHPSA3

Teknik Özellikler

Diode Element Material

SILICON

Diode Type

Standard

Maks. Çalışma Sıcaklığı

150°C

Fabrika Tedarik Süresi

8 Weeks

Number Of Elements

1

Applications

GENERAL PURPOSE

Peak Nonrepetitive Surge Current

41kA

Case Connection

ISOLATED

Pin Sayısı

107

Number Of Phases

1

Element Configuration

Single

Current Average Rectified Io

1100A

Output Current

1.7kA

Terminal Pozisyonu

UPPER

Max Repetitive Reverse Voltage Vrrm

1.8kV

Halogen Free

Not Halogen Free

Operating Temperature Junction

-40°C~150°C

Speed

Standard Recovery >500ns, > 200mA (Io)

Current Reverse Leakage Vr

150mA @ 1800V

Yayın Yılı

2012

Forward Current

1.07kA

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

ECCN Kodu

EAR99

Nem Hassasiyeti (MSL)

Not Applicable

Peak Reverse Current

1.5mA

RoHS Durumu

RoHS Compliant

Terminal Formu

UNSPECIFIED

Voltage Dc Reverse Vr Max

1800V

Terminal Sayısı

2

Min. Çalışma Sıcaklığı

-40°C

Parça Durumu

Active

Kurşunsuz

Lead Free

Voltage Forward Vf Max If

1.11V @ 3000A

Additional Feature

UL RECOGNIZED

Jesd30 Code

R-XUFM-X2

Montaj

Screw

HTS Kodu

8541.10.00.80

Reverse Voltage

1.8kV

Montaj Tipi

Chassis Mount

Ambalaj

Bulk
