338CKE025M

Teknik Özellikler

Voltage Rated Dc

25V

Voltage Rating Dc

25 VDC

RoHS

Details

Maks. Oturma Yüksekliği

1.043 26.50mm

Wire Form

LONG LEAD

ECCN Kodu

EAR99

Birim Ağırlık

0.261871 oz

Tolerance Or

20%

Seri

CKE

Terminal Sayısı

2

Ambalaj

Bulk

Equivalent Series Resistance Type

STANDARD

Esr Equivalent Series Resistance

100.5mOhm @ 120Hz

Montaj Tipi

Through Hole

Kılıf / Paket

Radial, Can

Çap

500μm

Terminal Shape

WIRE

Rad Hardened

No

Tolerans

±20%

Lead Length

15mm

Ürün Durumu

Active

Kapasitans

3300μF

Montaj

PCB, Through Hole

Nem Hassasiyeti (MSL)

1 (Unlimited)

Product Depth Mm

Not Required(mm)

Product Length Mm

Not Required(mm)

Lead Spacing Nom

7.5(mm)

Polarity

Polar

Life Hours

2000 hours

Lead Spacing

0.295 7.50mm

Ripple Current Low Frequency

1.645A @ 120Hz

Lead Pitch

7.493mm

Parça Durumu

Active

JESD-609 Kodu

e3

Product Height Mm

25(mm)

Dielectric Material

ALUMINUM (WET)

Polarization

Polar

Gerilim

25VDC

Maks. Çalışma Sıcaklığı

+ 105 C

Minimum Operating Temperature

- 40 C
