SR4P3-A1

Teknik Özellikler

RoHS Durumu

RoHS Compliant

Output Current

20mA

Min Output Voltage

400mV

Hysteresis

0.2 mT

Pin Sayısı

3

Çıkış Tipi

Current

Terminal

Wire Leads

Seri

SR4

Kurşunsuz Kodu

yes

Touchscreen

Resistive

Min Supply Voltage Dc

3.8V

Housing Material

Plastic

Kılıf / Paket

Cylinder, Threaded

Yayın Yılı

2012

Nem Hassasiyeti (MSL)

1 (Unlimited)

Body Height

25.4mm

Tip

Omnipolar Switch

Magnetic Field Rangemin

0.5 mT

Actuator Material

Magnet

Nominal Supply Current

11mA

Montaj

Panel

Terminal Stili

Wire Leads

Max Output Current

20mA

Çalışma Sıcaklığı

-40°C~85°C TA

Output Range

0.40V

Must Operate

2.5mT

Max Supply Voltage Dc

30V

Reach Svhc

Unknown

Leakage Current

10μA

Magnetic Field Rangemax

2.5 mT

Body Length Or Diameter

12.44mm

Ambalaj

Bulk

Parça Durumu

Active

Must Release

0.5mT

Fabrika Tedarik Süresi

17 Weeks

Besleme Gerilimi

3.8V~30V
