NSCSHHN001PDUNV

Teknik Özellikler

Pin Sayısı

4

Accuracy

±0.25%

Output

0 mV ~ 65 mV (5V)

Operating Supply Voltage

5V

Voltage Rated Dc

5V

Maximum Pressure

±10PSI (±68.95kPa)

Max Pressure

10 PSI

Çalışma Sıcaklığı

-40°C~85°C

Besleme Gerilimi

1.5V~12V

Port Size

Male - 0.16 3.94mm Tube Dual

Çıkış Tipi

Wheatstone Bridge

Nominal Supply Current

1.5mA

Kılıf / Paket

4-SIP, Dual Ports, Same Side

Terminal

PC Pin

Fabrika Tedarik Süresi

9 Weeks

Pressure Type

Differential

Parça Durumu

Active

Nem Hassasiyeti (MSL)

1 (Unlimited)

Port Style

Barbed

RoHS Durumu

RoHS Compliant

Yayın Yılı

2011

Terminal Stili

PC Pin

Applications

Board Mount

Seri

TruStability® NSC

Reach Svhc

No SVHC

Operating Pressure

±1PSI (±6.89kPa)

Sensorstransducers Type

PRESSURE SENSOR,STRAIN GUAGE
