HSCSRRN005PDAA5

Teknik Özellikler

Operating Pressure

±5PSI (±34.47kPa)

Response Time

1 ms

Port Style

Barbed

Besleme Gerilimi

4.75V~5.25V

Seri

TruStability® HSC

Fabrika Tedarik Süresi

10 Weeks

Operating Supply Voltage

5V

Kılıf / Paket

4-SIP, Dual Ports, Same Side

Özellikler

Amplified Output, Temperature Compensated

Max Pressure

30 PSI

Nominal Supply Current

2mA

Yüzey Montaj

NO

Mounting Feature

THROUGH HOLE MOUNT

RoHS Durumu

RoHS Compliant

Maximum Pressure

±30PSI (±206.84kPa)

Voltage Rated Dc

5V

Çalışma Sıcaklığı

-20°C~85°C

Terminal Stili

PC Pin

Çıkış Tipi

Analog Voltage

Terminal

PC Pin

Housing

CERAMIC

Pressure Rangemax

5 Psi

Output

0.5 V ~ 4.5 V

Parça Durumu

Active

Port Size

Male - 0.08 1.92mm Tube Dual

Applications

Board Mount

Pressure Type

Differential

Nem Hassasiyeti (MSL)

1 (Unlimited)

REACH Uyumluluk Kodu

unknown

Yayın Yılı

2011

Sensorstransducers Type

PRESSURE SENSOR,PEIZORESISTIVE

Accuracy

±0.25%
