HSCSHNN001PGAA5

Teknik Özellikler

Pressure Sensing Mode

GAGE

Nominal Supply Current

2mA

Pin Sayısı

4

Özellikler

Amplified Output, Temperature Compensated

Max Supply Current

3mA

RoHS Durumu

RoHS Compliant

Maximum Pressure

10PSI (68.95kPa)

Operating Pressure

1PSI (6.89kPa)

Besleme Gerilimi

4.75V~5.25V

Seri

TruStability® HSC

Response Time

1 ms

Port Style

Barbed

Montaj

Through Hole

Kılıf / Paket

4-SIP, Side Port

Fabrika Tedarik Süresi

7 Weeks

Operating Supply Voltage

5V

Port Size

Male - 0.19 4.78mm Tube

Output Voltage

4.5V

Applications

Board Mount

Output

0.5 V ~ 4.5 V

Parça Durumu

Active

Nem Hassasiyeti (MSL)

1 (Unlimited)

Pressure Type

Vented Gauge

Yayın Yılı

2011

REACH Uyumluluk Kodu

unknown

Accuracy

±0.25%

Sensorstransducers Type

PRESSURE SENSOR,PEIZORESISTIVE

Çalışma Sıcaklığı

-20°C~85°C

Voltage Rated Dc

5V

Çıkış Tipi

Analog Voltage

Terminal Stili

PC Pin

Housing

CERAMIC

Terminal

PCB

Pressure Rangemax

1 Psi
