26PCBFC6G

Teknik Özellikler

Operating Pressure

±5PSI (±34.47kPa)

Linearity

0.5 %

Body Length Or Diameter

12.7mm

Pressure Type

Compound

Özellikler

Temperature Compensated

Body Height

18.8mm

Offsetnom

0MV

Seri

26PC

Output Voltage

50mV

Accuracy

±0.5%

Kurşunsuz Kodu

yes

Çalışma Sıcaklığı

-40°C~85°C

Operating Supply Voltage

10V

Çıkış Tipi

Wheatstone Bridge

Max Pressure

20 PSI

Fabrika Tedarik Süresi

8 Weeks

Response Time

1 ms

Montaj

Through Hole

Weight

2g

Yayın Yılı

1998

Output

0 mV ~ 50 mV (10V)

Port Size

Male - 0.18 4.6mm Tube

Kılıf / Paket

4-SIP Module

RoHS Durumu

RoHS Compliant

REACH Uyumluluk Kodu

unknown

Applications

Board Mount

Nem Hassasiyeti (MSL)

1 (Unlimited)

Pin Sayısı

4

Pressure Rangemax

5 Psi

Terminal Stili

PC Pin

Port Style

Barbless

Terminal

PC Pin

Parça Durumu

Obsolete

Besleme Gerilimi

2.5V~16V

Maximum Pressure

±20PSI (±137.9kPa)

Sensorstransducers Type

PRESSURE SENSOR,PEIZORESISTIVE

Direnç

11.5kOhm
