Adet bazlı fiyat
- 1+ adet$33.35
- 10+ adet$31.46
- 100+ adet$29.68
- 500+ adet$28.00
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Weight
- 272g
- Orientation
- Straight
- Overtravel
- 0.003 (0.076mm)
- Current Rating Amps
- 5A AC/DC
- Body Length Or Diameter
- 19.84mm
- Yayın Yılı
- 2007
- Pretravelmax
- 0.5 mm
- Switch Function
- On-Mom
- Contact Currentdcmax
- 5A
- Contact Currentacmax
- 5A
- REACH Uyumluluk Kodu
- unknown
- Operating Force
- 99gf
- Voltage Rated Dc
- 30V
- Contact Ac Max Rating R Load
- 5A@250VAC
- Akım Değeri
- 5A
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Round (Pin Plunger)
- Voltage Rated Ac
- 250V
- Body Height
- 7.67mm
- Differential Travel
- 0.001 (0.025mm)
- Max Voltage Rating Dc
- 30V
- Pretravel
- 0.020 (0.5mm)
- ECCN Kodu
- EAR99
- Terminal Stili
- Solder Turret
- Actuator Travel
- 0.576 mm
- HTS Kodu
- 8536.50.70.00
- Fabrika Tedarik Süresi
- 7 Weeks
- Circuit
- SPDT
- Housing Material
- Phenolic
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Montaj Tipi
- Chassis Mount
- Mechanical Life
- 10,000,000 Cycles
- Seri
- SM
- Body Breadth
- 6.35 mm
- Release Force
- 28gf
- Contact Materials
- Silver
- Operating Position
- 0.330 (8.4mm)
- RoHS Durumu
- RoHS Compliant
- Çalışma Sıcaklığı
- -55°C~125°C
