Adet bazlı fiyat
- 1+ adet$9.32
- 10+ adet$8.79
- 100+ adet$8.30
- 500+ adet$7.83
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mechanical Life
- 10,000,000 Cycles
- Seri
- SM
- Release Force
- 28gf
- Contact Materials
- Silver
- Operating Position
- 0.330 (8.4mm)
- RoHS Durumu
- RoHS Compliant
- Çalışma Sıcaklığı
- -55°C~125°C
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Terminal
- Solder
- Contact Dc Max Rating R Load
- 5A@30VDC
- Parça Durumu
- Active
- HTS Kodu
- 8536.50.70.00
- Fabrika Tedarik Süresi
- 10 Weeks
- Circuit
- SPDT
- Housing Material
- Phenolic
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Depth
- 6.35mm
- Montaj Tipi
- Chassis Mount
- Contact Ac Max Rating R Load
- 5A@250VAC
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 5A
- Actuator Material
- Plastic
- Reach Svhc
- No SVHC
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Round (Pin Plunger)
- Voltage Rated Ac
- 250V
- Body Height
- 9.04mm
- Differential Travel
- 0.004 (0.1mm)
- Max Voltage Rating Dc
- 30V
- Pretravel
- 0.020 (0.5mm)
- Terminal Stili
- Solder Turret
- ECCN Kodu
- EAR99
- Weight
- 272g
- Max Current Rating
- 5A
- Orientation
- Straight
- Overtravel
- 0.005 (0.13mm)
- Current Rating Amps
- 5A AC/DC
- Switch Function
- On-Mom
- Pretravelmax
- 0.51 mm
