Adet bazlı fiyat
- 1+ adet$20.85
- 10+ adet$19.67
- 100+ adet$18.55
- 500+ adet$17.50
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pretravelmax
- 0.5 mm
- Ambalaj
- Bulk
- Contact Materials
- Silver
- Contact Currentacmax
- 7A
- Max Voltage Rating Ac
- 250V
- Terminal Kaplaması
- Gold (Au)
- Terminal
- Solder
- Voltage Rated Ac
- 250V
- Contact Currentdcmax
- 7A
- ECCN Kodu
- EAR99
- Terminal Stili
- Solder Turret
- Overtravel
- 0.004 (0.1mm)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Differential Travel
- 0.005 (0.13mm)
- Montaj Tipi
- Chassis Mount
- Weight
- 136g
- Depth
- 5.08mm
- Voltage Rated Dc
- 28V
- Seri
- SX
- Body Height
- 8.89mm
- Max Current Rating
- 7A
- Actuator Material
- Plastic
- Contact Ac Max Rating R Load
- 7A@250VAC
- Mechanical Life
- 1,000,000 Cycles
- Switch Function
- On-Mom
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Position
- 0.320 (8.13mm)
- Housing Material
- Phenolic
- Actuator Type
- Round (Pin Plunger)
- Pretravel
- 0.020 (0.5mm)
- HTS Kodu
- 8536.50.70.00
- Uzunluk
- 12.7mm
- Montaj
- Chassis Mount, Screw, Solder
- JESD-609 Kodu
- e4
- Yayın Yılı
- 2007
- Orientation
- Straight
- Max Voltage Rating Dc
- 28V
- Contact Dc Max Rating R Load
- 7A@28VDC
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 7A
