1TP8-7

Teknik Özellikler

Terminal Stili

Screw Terminal

Özellikler

Sealed

Parça Durumu

Active

Contact Current Rating

15A

Actuator Marking

Varies by Cap

Sealing

DUST PROOF; WATER PROOF

Ambalaj

Bulk

HTS Kodu

8536.50.90.40

Seri

TP

Montaj

Flush, Panel

Montaj Tipi

Panel Mount, Flange

Çalışma Sıcaklığı

-54°C~71°C

Max Voltage Rating Dc

250V

Switch Function

Mom-Off-Mom

Orientation

Straight

Actuator Material

Plastic

Current Rating Amps

10A AC

Terminal

Screw

Actuator Type

Actuator Arm, Cap Required

Contact Materials

Cadmium, Silver

RoHS Durumu

RoHS Compliant

Akım Değeri

10A

Panel Cutout Dimensions

Rectangular - 38.40mm x 23.90mm

Illumination Type

Illuminated

Voltage Rated Ac

125V

Body Breadth

19.56 mm

Max Voltage Rating Ac

277V

Reach Svhc

No SVHC

Switch Type

ROCKER SWITCH

Fabrika Tedarik Süresi

26 Weeks

Circuit

SPDT

Body Length Or Diameter

55.12mm

Kurşunsuz Kodu

yes

Body Height

36.83mm

Contact Ac Max Rating R Load

10A@277VAC

Nem Hassasiyeti (MSL)

1 (Unlimited)

ECCN Kodu

EAR99

Contact Plating

Cadmium, Silver
