Adet bazlı fiyat
- 1+ adet$23.05
- 10+ adet$21.74
- 100+ adet$20.51
- 500+ adet$19.35
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Current Rating Amps
- 10A AC
- Terminal
- Solder
- Housing Material
- Phenolic
- Actuator Type
- Round (Pin Plunger)
- Mechanical Life
- 7,000,000 Cycles
- Depth
- 17.5mm
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 10A
- Yayın Yılı
- 2004
- Voltage Rated Ac
- 250V
- Terminal Stili
- Solder Lug
- Contact Current Rating
- 10A
- Parça Durumu
- Active
- Differential Travel
- 0.025 (0.6mm)
- Ambalaj
- Bulk
- HTS Kodu
- 8536.50.70.00
- Seri
- TB
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Weight
- 907g
- Montaj Tipi
- Chassis Mount
- Çalışma Sıcaklığı
- -55°C~125°C
- Switch Function
- On-Mom
- Orientation
- Straight
- Body Height
- 12.7mm
- Contact Ac Max Rating R Load
- 10A@250VAC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 10A
- Operating Position
- 0.460 (11.7mm)
- Throw Configuration
- DPDT, SPDT
- Material
- Plastic
- Pretravel
- 0.060 (1.5mm)
- Actuator Travel
- 1.77 mm
- ECCN Kodu
- EAR99
- Operating Force
- 198 ~ 368gf
- Body Breadth
- 12.7 mm
- Max Voltage Rating Ac
- 250V
- Pretravelmax
- 1.52 mm
- Uzunluk
- 31.8mm
- Reach Svhc
- No SVHC
- Switch Type
- SNAP ACTING/LIMIT SWITCH
