Adet bazlı fiyat
- 1+ adet$30.54
- 10+ adet$28.81
- 100+ adet$27.18
- 500+ adet$25.64
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Max Voltage Rating Dc
- 28V
- Montaj
- Chassis Mount, Screw, Solder
- Overtravel
- 0.004 (0.1mm)
- Reach Svhc
- Unknown
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 7A
- Max Current Rating
- 7A
- Fabrika Tedarik Süresi
- 6 Weeks
- Orientation
- Straight
- Actuator Material
- Plastic
- Current Rating Amps
- 7A AC/DC
- Terminal
- Turret
- Çalışma Sıcaklığı
- -55°C~125°C
- Parça Durumu
- Active
- Operating Force
- 141gf
- Weight
- 1.36g
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2007
- Circuit
- SPDT
- Uzunluk
- 12.7mm
- Release Force
- 28gf
- Mechanical Life
- 1,000,000 Cycles
- Montaj Tipi
- Chassis Mount
- Differential Travel
- 0.005 (0.12mm)
- Switch Function
- On-Mom
- Ambalaj
- Bulk
- Actuator Type
- Round (Pin Plunger)
- Pretravel
- 0.020 (0.5mm)
- Depth
- 5.08mm
- Voltage Rated Dc
- 28V
- Housing Material
- Phenolic
- Operating Position
- 0.312 (7.9mm)
- Voltage Rated Ac
- 250V
- Contact Current Rating
- 7A
- Seri
- SX
- RoHS Durumu
- RoHS Compliant
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Terminal Stili
- Solder Turret
