Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Genişlik
- 94mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Stainless Steel
- Additional Feature
- 2 SWITCHES ARE AVILABLE
- Actuator Type
- Round (Pin Plunger)
- Yayın Yılı
- 1999
- Orientation
- Straight
- Pretravel
- 0.040 (1.0mm)
- HTS Kodu
- 8536.50.70.00
- Montaj
- Panel
- Max Voltage Rating Dc
- 28V
- Contact Dc Max Rating R Load
- 5A@28VDC
- Parça Durumu
- Active
- Release Force
- 1814gf
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 5A
- Current Rating Amps
- 5A DC
- Circuit
- SPDT x 2
- Operating Force
- 2722 ~ 5443gf
- Fabrika Tedarik Süresi
- 8 Weeks
- Sealing
- CORROSION PROOF; EPOXY TERMINAL SEALED
- Çalışma Sıcaklığı
- -54°C~85°C
- Pretravelmax
- 1.02 mm
- REACH Uyumluluk Kodu
- unknown
- Ambalaj
- Bulk
- Terminal
- Receptacle
- Contact Currentdcmax
- 5A
- Throw Configuration
- DPDT
- Ingress Protection
- Environment Sealed
- Terminal Stili
- Connector
- Overtravel
- 0.250 (6.35mm)
- ECCN Kodu
- EAR99
- Body Length Or Diameter
- 25.4mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Differential Travel
- 0.020 (0.5mm)
- Actuator Travel
- 7.37 mm
- Montaj Tipi
- Panel Mount
- Body Height
- 73.41mm
- Voltage Rated Dc
- 28V
- Seri
- EN
