Teknik Özellikler
- Terminal
- Solder
- Contact Currentdcmax
- 1A
- Voltage Rated Ac
- 125V
- Pretravelmax
- 0.5 mm
- Ambalaj
- Bulk
- Contact Materials
- Gold
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Terminal Stili
- Solder Turret
- Overtravel
- 0.010 (0.25mm)
- ECCN Kodu
- EAR99
- Depth
- 5.08mm
- Montaj Tipi
- Chassis Mount
- Weight
- 136g
- Differential Travel
- 0.001 (0.025mm)
- Mechanical Life
- 10,000,000 Cycles
- Switch Function
- On-Mom
- Actuator Material
- Plastic
- Max Current Rating
- 1A
- Body Height
- 8.89mm
- Voltage Rated Dc
- 30V
- Seri
- SX
- Housing Material
- Phenolic
- Operating Position
- 0.320 (8.13mm)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 1995
- Orientation
- Straight
- Pretravel
- 0.020 (0.5mm)
- HTS Kodu
- 8536.50.70.00
- Uzunluk
- 12.7mm
- Montaj
- Chassis Mount, Screw, Solder
- Reach Svhc
- Unknown
- Actuator Type
- Round (Pin Plunger)
- Kurşunsuz Kodu
- yes
- Max Voltage Rating Dc
- 30V
- Contact Dc Max Rating R Load
- 1A@30VDC
- Operating Force
- 170gf
- Fabrika Tedarik Süresi
- 7 Weeks
- Çalışma Sıcaklığı
- -55°C~125°C
- Release Force
- 14gf
- Parça Durumu
- Active
