11SX96-T

Teknik Özellikler

Contact Dc Max Rating R Load

5A@28VDC

Kurşunsuz Kodu

yes

Montaj

Chassis Mount, Screw, Solder

Current Rating Amps

5A AC/DC

Ambalaj

Bulk

Fabrika Tedarik Süresi

12 Weeks

Parça Durumu

Active

Mechanical Life

10,000,000 Cycles

Switch Type

SNAP ACTING/LIMIT SWITCH

Max Voltage Rating Dc

28V

ECCN Kodu

EAR99

Depth

5.08mm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Actuator Type

Round (Pin Plunger)

Switch Function

On-Mom

Actuator Material

Plastic

Seri

SX

Montaj Tipi

Chassis Mount

Voltage Rated Dc

28V

HTS Kodu

8536.50.70.00

Terminal Stili

Solder Turret

Reach Svhc

No SVHC

Weight

136g

Uzunluk

12.7mm

Yayın Yılı

1995

Contact Currentdcmax

5A

Çalışma Sıcaklığı

-55°C~125°C

Differential Travel

0.001 (0.025mm)

Pretravel

0.020 (0.5mm)

Pretravelmax

0.5 mm

Terminal

Solder

Release Force

14gf

Contact Materials

Silver

Contact Ac Max Rating R Load

5A@250VAC

Circuit

SPDT

Voltage Rated Ac

115V

Contact Currentacmax

5A

Body Height

8.89mm

Max Current Rating

5A

Orientation

Straight
