Adet bazlı fiyat
- 1+ adet$10.29
- 10+ adet$9.71
- 100+ adet$9.16
- 500+ adet$8.64
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Actuator Type
- Round (Pin Plunger)
- Seri
- SM
- Switch Function
- On-Mom
- Montaj Tipi
- Chassis Mount
- HTS Kodu
- 8536.50.70.00
- Voltage Rated Dc
- 30V
- Montaj
- Chassis Mount, Screw
- Contact Dc Max Rating R Load
- 5A@30VDC
- Kurşunsuz Kodu
- yes
- Current Rating Amps
- 5A AC/DC
- Fabrika Tedarik Süresi
- 10 Weeks
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 6.35mm
- ECCN Kodu
- EAR99
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Parça Durumu
- Active
- Mechanical Life
- 10,000,000 Cycles
- Yayın Yılı
- 2015
- Uzunluk
- 19.84mm
- Contact Currentdcmax
- 5A
- Contact Current Rating
- 5A
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Weight
- 272g
- Circuit
- SPDT
- Contact Ac Max Rating R Load
- 5A@250VAC
- Contact Materials
- Gold, Silver
- Contact Currentacmax
- 5A
- Voltage Rated Ac
- 250V
- Body Height
- 9.08mm
- Orientation
- Straight
- Max Current Rating
- 5A
- Overtravel
- 0.005 (0.13mm)
- RoHS Durumu
- RoHS Compliant
- Max Voltage Rating Ac
- 250V
- Çalışma Sıcaklığı
- -55°C~125°C
- Pretravel
- 0.020 (0.5mm)
- Pretravelmax
- 0.51 mm
- Differential Travel
- 0.004 (0.1mm)
- Release Force
- 28gf
