Adet bazlı fiyat
- 1+ adet$38.80
- 10+ adet$36.60
- 100+ adet$34.53
- 500+ adet$32.57
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ambalaj
- Bulk
- Fabrika Tedarik Süresi
- 10 Weeks
- Mechanical Life
- 10,000,000 Cycles
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 6.35mm
- ECCN Kodu
- EAR99
- Max Voltage Rating Dc
- 30V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Dc Max Rating R Load
- 1A@30VDC
- Kurşunsuz Kodu
- yes
- Montaj
- Through Hole
- Current Rating Amps
- 1A AC/DC
- Montaj Tipi
- Through Hole
- Voltage Rated Dc
- 30V
- HTS Kodu
- 8536.50.70.00
- Actuator Type
- Round (Pin Plunger)
- Switch Function
- On-Mom
- Actuator Material
- Plastic
- Seri
- SM
- Weight
- 272g
- Reach Svhc
- No SVHC
- Terminal Stili
- PC Pin
- Contact Currentdcmax
- 1A
- Contact Current Rating
- 1A
- Uzunluk
- 19.84mm
- Yayın Yılı
- 1995
- Differential Travel
- 0.004 (0.1mm)
- Pretravel
- 0.020 (0.5mm)
- Pretravelmax
- 0.5 mm
- Terminal
- Solder
- Release Force
- 28gf
- Çalışma Sıcaklığı
- -55°C~125°C
- Body Height
- 9.04mm
- Orientation
- Straight
- Max Current Rating
- 1A
- Overtravel
- 0.005 (0.13mm)
- RoHS Durumu
- RoHS Compliant
- Contact Ac Max Rating R Load
- 1A@125VAC
- Contact Materials
- Gold
