Adet bazlı fiyat
- 1+ adet$8.54
- 10+ adet$8.06
- 100+ adet$7.60
- 500+ adet$7.17
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Depth
- 6.4mm
- Contact Timing
- SNAP ACTION
- Contact Materials
- Silver
- RoHS Durumu
- RoHS Compliant
- HTS Kodu
- 8536.50.70.00
- Contact Currentdcmax
- 5A
- Actuator Length
- 305mm
- Terminal Stili
- Solder Turret
- Contact Currentacmax
- 5A
- Terminal
- Solder
- Kurşunsuz
- Lead Free
- Actuator Type
- Lever, Roller
- Montaj
- Chassis Mount, Screw, Solder
- Max Current Rating
- 5A
- Çalışma Sıcaklığı
- -55°C~125°C
- Current Rating Amps
- 5A AC/DC
- Housing Material
- Phenolic
- Orientation
- Straight
- Reach Svhc
- Unknown
- Voltage Rated Dc
- 30V
- Pretravel
- 0.218 (5.5mm)
- Body Height
- 9.04mm
- ECCN Kodu
- EAR99
- Uzunluk
- 19.8mm
- Operating Position
- 0.562 (14.3mm)
- Seri
- SM
- Yayın Yılı
- 1995
- Weight
- 272g
- Ambalaj
- Tray
- Overtravel
- 0.030 (0.76mm)
- Voltage Rated Ac
- 250V
- Genişlik
- 20.3mm
- Montaj Tipi
- Chassis Mount
- Release Force
- 57gf
- Mechanical Life
- 10,000,000 Cycles
- Switch Function
- On-Mom
- Additional Feature
- UL, CSA, CE, ENEC APPROVED
- Contact Current Rating
- 5A
- Circuit
- SPDT
- Pretravelmax
- 5.56 mm
